In the Project Manager, right-click the project name, and select Descriptions.

If AEGS is not the active project, in the Project Manager, right-click AEGS and select Activate.

Click Project tab Project Tools panel Manager.

Save the file as AEGS_WDTITLE.WDL in the project folder Users\\Aedata\Proj\Aegs.

Use any generic text editor like Notepad or Wordpad and start a new text file.

What you want to see when AutoCAD Electrical displays a title block-related dialog box is not “LINE4” but “Job Number.” A text file with a WDL extension defines the custom labels. For example, you have linked the AutoCAD Electrical data “LINE4” value to the “JOB#” attribute on the title block.

You can change these labels so they match up with the link to the title block. The title block and project description dialog boxes in AutoCAD Electrical display generic labels like “LINE1”, “LINE2”, and so on. Define the labels for project description lines displayed on dialog boxes.
